Technical description

• General
  • Processor: ATMEL 89LS52
  • CPU Speed: 22.118 MHz
  • Power:+5V ±5% 0.94Atyp.4.7V
  • System Reset
  • Watchdog timer. VCC sensing (reset below 4.70Vtyp.
  • Compatibility с PC 104;
  • Real time clock
• Memory
  • System RAM 32KB SDRAM
  • Flash Interface: High retention.Compact Flash socket.Flash 8MB
• Network interfase
  • Ethernet: Auto detects 10BaseT.
  • TX port. StandardRJ-45 connector
  • Network Boot: Option Support TCP/IP(DHCP)remote boot protocols
• Device I/O
  • LCD Interface
  • Com1: RS-232compatible, 115baud max.
  • Other:Two general-purpose timer inputs; Beeper
• Mechanical
  • Board Size; 90mmx96mm
  • Storage Temperature : от -40º до +85º C
  • Operating Temperature :от 0º до + 60º C no airflow
