Application

• Line protection of digital E1 streàms for business needs
• High quality of service
• Effective solution with easy maintenance

Technical Description

• Operation in 1+1 protection mode
• Automatic Protection Switch
• Switch over time can be configured
• Criteria for switching to the protection path:
  • Loss of frame alignment to line signal
  • High Bit Error Rate (BER) in received line signal
  • BER threshold, configurable for APS
• Interface base and protected stream:
  • Mode: Å1 G.703/G.704
  • Bit rates: from 64kbit/s to 2048kbit/s
  • Impedance: 120 ohms or 75 ohms with an adapter
  • Connector: RJ 45
  • Line code: HDB3
  • Number of ports: 6
  • Number of E1 streams protection: 2
  • Max cable attenuation: 1024kHz/6dB
• Management: local and remote
• Management interface: RS.232
• Power supply
  • With AC/DC converter: 230V/22V, AC/DC
• Temperature: from -5°C to +45°C
• Dimension: 238x189x31 mm
• Weight: 600g
